Description

General Information
Image Sensor
1/2.8” 3 Megapixel CMOS

Effective Pixels
3MP (2304 × 1296)

Frame Rate
1～25 fps

Lens
3.2 mm @ F2.0, 135° / 110° / 60°

IR Distance
Night Visibility up to 30m

Min. Illumination
Color: 0.1 Lux @ F2.0
Black/White: 0.01 Lux @ F2.0
Day/Night: Auto (ICR) / Color / B & W

Video Compression
H.264

Bit Rate
32 Kbps～2 Mbps

Audio Input / Output
Built-in Mic/Speaker

Smart Alarm
PIR Human Detection
PIR Detection Range: Max. 9m
PIR Angle: 120°

Network & Connectivity
Wireless Network
2.4 GHz Wi-Fi (IEEE802.11 b/g/n/ax)

Others
Communication Protocol: HTTP, TCP/IP, DHCP, DNS
Interface Protocol: Private
Supported Mobile Phone OS: iOS 9 or later, Android 5 or later
Security: AES128

Power
Power Supply
DC 5V / 1A

Power Consumption
Up to 2W

Others
Battery Capacity: 5200mAh
Stand-by Consumption: 200～1000 µA (average)
Working Current: 150～200 mA (IR LED off)
Stand-by Time: 6 Months
Working Time: 1.5～2 Months (varies based on Settings, Usage & Temperature)

Physical Specification
Dimension
64 × 59 × 101 mm

Weight
265 g

Operating Temperature
-20°C～50°C

Others
Free 10 Years Cloud Storage
IP Rating: IP65

Warranty Information
Warranty
2 Years
